Protect Your Family and Business with Our Bushfire Screens in Sydney, Penrith & the Blue Mountains
- All ClearShield products are suitable for use as bushfire ember screens at any BAL Level
- Approved for standalone use in bushfire applications up to and including BAL-40
- ClearShield protects the complete window thus allowing the occupants easy escape in an emergency.
All ClearShield products are bushfire rated screens that have been approved for use in bushfire applications up to and including the highest FZ level of requirement under AS3959.
ClearShield
Emergency Exit Screens are also very useful as a bushfire screen where the application requires the screen to protect the complete window thus allowing the occupants easy escape in an emergency.
ClearShield Bushfire Screens – Technical Data
Aluminium Framing
| Grade | 6063-T6 |
| Coating | Anodised – min 15um to AS1213-2000 |
| Powdercoating – Chromate Pre-treatment and powdercoated to AS3715-2002 | |
| Warranty | As per Coating Selection |
Stainless Steel Sheet
| Grade: | T304 |
| Finish: | 2B Black |
| Warranty: | 15 Years, subject to adhering to the recommended cleaning schedule |
| Coating: | Powdercoating – Oxsilane Chrome Free Pre-treatment and powdercoated to AS3715-2002 |
| Open Area: | 39%-41% (Ember Screen) – Less than 20% (Shutter) |
| Dimensions: | Ø 2mm Round Holes, 60° Staggered Pitch, 3mm Spacings, 0.8mm Thick |
| Or: | Ø 2mm Round Holes, 60° Staggered Pitch, 5mm Spacings, 0.8mm Thick (Shutters Only) |
Compliance
| Standard | Test No. | Product | Suitability |
|---|---|---|---|
| AS3959-2009 | 2452600 | All ClearShield Perforated Stainless Steel Products | All BAL Zones |
| AS3959 Part 3.7 | 26521 | ClearShield Bushfire Shutters | Up to BAL-40 |
Need more information about our Bushfire Screens? Call 02 4721 5241.
